Comacchio machines

Comacchio-machines maken deel uit van een breed scala aan rupsbanden, gespecialiseerd in civieltechnische werken, geotechnische en milieuonderzoeken … Momenteel bieden we u de onderstaande modellen aan, klik op de naam onder de foto voor meer informatie over elk van deze modellen.

Comacchio MC 4D

The MC 4D is a hydraulic drilling rig with separate power pack, specifically designed for the execution of ground engineering works in confined or low overhead spaces and difficult access jobsites, inside buildings, basements and small tunnels.

This is possible due to the rig’s wide range of allowable movements. This machine is equipped with a soundproof diesel power pack.

Options :

  • Year of manufacture : 2017
  • Weight : drilling unit : 5 000 kg , powerpack : 2 750 kg
  • Max pull up/down 3500 daN
  • Mast extension length : 300 / 600 / 800 / 1200 mm
  • Radio control for drilling + tracks
  • Drilling unit + powerpack on steel crawler including variable width and rubber shoe
  • Hydraulic hoses between powerpack and drilling unit : 20 meters
  • Rod holder + rod breaker with max inner diameter 220 mm
  • Motor Deutz 100 kW
  • Winch 1000 kg
  • Head slide off the way
  • High pressure pump + cleaner gun
  • D.T.H. hammer Lubricator
  • Preequiped for jetgrouting
  • Preequiped for drilling parameter recorder

Equipped with the Eurodrill RH 10 X drifter ( rotary head + percussion unit ).

2 gears motor with a max torque of 8.7 kNm and max rotation speed of 110 RPM.

Comacchio GEO 305

The GEO 305 is a compact sized hydraulic drilling rig mounted on rubber tracks and covering the full spectrum of geotechnical activities, such as soil investigations carried out with destructive and non-destructive techniques, sample

collection, installation of piezometers, inclinometers and other geotechnical instrumentation.

Besides geotechnical investigation in the strict sense, this drilling rig can be used for environmental studies and monitoring activities.

Options :

  • Year of manufacture : 2009
  • Weight : 3 550 kg
  • Mast in 2 elements
  • Max pull up 3 500 daN , max pull down 3 500 daN
  • Casing extractor 8 000 daN
  • Remote control for tracks
  • Rod holder + rod breaker with max inner diameter 220 mm
  • Motor Deutz 55 kW
  • Winch 500 kg
  • Head slide off the way
  • Water/mud pump high flow
  • Rubber track
  • LED lamps

Rotary head Comacchio CT 38 :

Torque : 306 / 720 daNm

Rotation speed : 90 / 45 RPM

Output thread : 2 3/8 IF box

Comacchio MC 12

The MC 12 is a versatile and powerful hydraulic drilling rig designed for civil engineering works such as micropiles, anchors, jet grouting and ground improvement in general.

The rig’s patented mast articulation ability, compact size and variety of mast positions and inclinations allow for operation even in confined spaces.

Options :

  • Year of manufacture : 2017
  • Weight : 13 100 kg
  • Mast in 2 elements + crown block
  • Max pull up 6000 daN , max pull down 6000 daN
  • Casing extractor 8 000 daN
  • Radio control for drilling + tracks
  • Rod holder + rod breaker with max inner diameter 320 mm
  • Motor Deutz 115 kW
  • Winch 2000 kg
  • Head slide off the way
  • Water/mud pump 200 l/min
  • High pressure cleaner + pump
  • Rubber shoe for steel track
  • LED lamps
  • D.T.H. hammer Lubricator
  • Preequiped for jetgrouting
  • Preequiped for drilling parameter recorder

Equipped with the Eurodrill RH 15 X drifter ( rotary head + percussion ) :

Tableau

Comacchio MC 900P

Verkocht

Comacchio MC F04

Verkocht

Comacchio MC 8

The MC 8 is an extremely versatile and powerful small/medium size hydraulic drilling rig, designed for civil engineering works such as micropiles, anchors, jet grouting and consolidations in general. The patented mast articulation abilities, compact size and large variety of movements and inclinations make the MC 8 suitable to be used even in very small spaces.

Specifications :

  • Year of manufacture : 2018
  • Weight : 8 900 kg
  • Max pull up 5000 daN , max pull down 5000 daN
  • Radio control for drilling + tracks
  • Motor Deutz 100 kW
  • Winch 1000 kg
  • Head slide off the way
  • High pressure cleaner + pump
  • Rubber shoe for steel track
  • LED lamps
  • Preequiped for jetgrouting
  • Preequiped for drilling parameter recorder

Equipped with the Eurodrill RH 10 X drifter ( rotary head + percussion ).

2 gears motor with a max torque of 8.7 kNm and max rotation speed of 110 RPM.

Swalmec is able to offer you rental solution with operator, equipment and tools.

Rental of our Comacchio MC8 with extra air compressor, operator and tools in the lock of Ampsin in Belgium.
